Specification
- Dimensions: 246 mm x 60 mm x 180 mm
- FreqResponse: 10 Hz to 70 kHz
- MaxWattage1: –
- MaxWattage2: 250 W x 2
- MaxWattage4: 170 W x 2
- MaxWattageBridge: 500 W x 1
- NumOfChannels: 2 / 1
- TotHarmonicDistortion: < 0.05%
- WattageRMS1: –
- WattageRMS2: 95 W x 2
- WattageRMS4: 60 W x 2
- WattageRMSBridge: 190 W x 1
- What is in the box: Power cable, USB cable, Quick Start Guide, Software license notice, Precautions for Use, Warranty (for some regions)
Product Features
- LPF: Use low-pass filter for subwoofer connection
- Automatic Signal Sensing and Turn-On: Pioneer‘s amplifier automatically selects an input signal mode between the RCA level and the speaker level detecting an input signal. Further, when the receiver is turned on, the amplifier will automatically turn on. When connected with an OEM receiver or receiver without RCA input using speaker line, the amplifier has its power turned on in sync with the receiver.
