Specification
- Woofer: 8″ (200mm)
- Amplifier Power: 125W RMS
- Frequency Response: 35Hz – 120Hz
- Fuse: 15A
- Maximum Current Draw: 12A
- Quiescent Current Draw: <800mA
- Input Sensitivity: 0.05V – 2V Line-Level Input; 0.5V – 20V High-Level Input
- Crossover Frequency: 50Hz – 120Hz
- Crossover Slope: 12dB/octave
- Bass Boost: 0dB to +9dB @ 70Hz
- (L x W x H): 13-9/16″ x 9-7/8″ x 2-13/16″ (344mm x 250mm x 71mm)
Product Features
- Efficient Class D Amplifier: The built-in Class D amp generates minimal heat and draws less power, making it an efficient choice for any vehicle’s electrical system.
- Intelligent Electronic Design: High-pass filters and limiters deliver consistent, reliable performance—even at high output levels.
- Crossover Control: Manually adjust the crossover frequency (50Hz–120Hz) to fine-tune the upper and mid-bass output for a seamless transition with your main speakers.
- Flexible EQ Adjustments: Balance your bass effortlessly. Use level control to match volume with the rest of your system, and fine-tune low-frequency response using the Bass Boost control.
- Line- and High-Level Inputs: Enjoy greater installation flexibility with support for both line-level and speaker-level connections. Includes an input load switch to optimize performance based on your setup.
- Wired Remote Level Control: Compatible with the included JBL GTO-RBC remote, allowing you to adjust bass levels easily from the driver’s seat.
- Proprietary, shallow-profile woofer: The 8″ (200mm) woofer in the BassPro SL2 is designed specifically to provide low distortion and great bass performance in an ABS enclosure with a remarkably compact footprint.
Remarks
- 1 x Powered woofer enclosure
- 4 x Mounting screws
- 1 x Remote bass level control
- 1 x Owner’s manual
